The Global-Series Handheld welding CW fiber lasers Range from 600W -3000W. This series laser source dedicated for both water-cooled and air-cooled handheld welding can be supported with one hand and comes with an external AC power supply, making it more efficient for integration into welding machines. Its optical cable is adapted to locking head and the armored pipe diameter is smaller, which reduces drag force during handheld welding.
2000W Global-Series CW Fiber Laser for Handheld Welding
Technical Data
| Item / Model | Raycus 2000W Single Module CW Fiber Laser |
| Average Output Power (W) | 2000 |
| Output Power Instability | ±1% |
| Central Wavelength (nm) | 1080 ±5 |
| Maximum Modulation Frequency (kHz) | 5 |
| Red Laser | Yes |
| Output Connector | IQB |
| Polarization State | Random |
| Output Fiber Core Diameter (µm) | 25 (Customizable) |
| Output Fiber Length (m) | 10 (Customizable) |
| Beam Quality (M²) | <1.8 |
| Input Power (V AC) | 220 |
| Max Power Consumption | < 6.5 kW |
| Control Mode | Control Line / Bluetooth / Ethernet |
| Power Adjustment Range (%) | 1 – 100 |
| Dimensions (mm) | 340 × 390 × 80 |
| Weight (kg) | 3 ±1 |
| Working Temperature (°C) | 10 – 40 |
| Cooling Method | Water Cooling |
-
Chillers
Water chiller units CWFL-1500
