Dual-Circuit Water-Cooled Chillers features
1. With environmental refrigerant;
2. ±1℃ precise temperature control;
3. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;
4. Dual temperature to satisfy different needs of fiber laser and the laser head;
5. With Ion adsorption filtrating and test functions conform to fiber laser device operating requirements;
6. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
7. Multiple power specifications; CE approval; RoHS approval; REACH approval;
8. Optional heater and water filter.
9. Support Modbus-485 communication protocol, which can realize the communication between the laser system and multiple water chillers to achieve two functions: monitoring the working status of the chillers and modifying the parameters of the chillers.
THE WARRANTY IS 2 YEARS AND THE PRODUCT IS UNDERWRITTEN BY INSURANCE COMPANY.
Specification
| CWFL-6000 | CWFL-6000EN | CWFL-6000FN |
|---|---|---|
| Voltage | AC 3P 380V | AC 3P 380V |
| Frequency | 50 Hz | 60 Hz |
| Current | 3.4 ~ 11.5 A | 3.4 ~ 11.2 A |
| Machine Power | 5.71 kW | 6.01 kW |
| Electric Assisted Power | 400W + 1800W | |
| Precision | ±1°C | |
| Reducer | Capillary | |
| Pump Power | 1.1 kW | |
| Tank Capacity | 70 L | |
| Inlet and Outlet | Rp1/2″ + Rp1″ | |
| Lift | 53 M | |
| Rated Flow | 2 L/min + 50 L/min | |
| N.W. | 200 Kgs | |
| G.W. | 260 Kgs | |
| Dimension | 105 × 71 × 133 cm (L × W × H) | |
| Package Dimension | 132 × 86 × 153 cm (L × W × H) | |
