Cutting HeadBH03K Formerly as BW101– GS SERIES
+ Free Shipping
Features –
- 4-in-one laser control system (Cut/Weld/WeldSeam Clean/Remote Clean) and HMI panel are included.
- Single axis wobble with adjustable line spot 0-5mm.
- Multiple safety protection with auto beam off function once the nozzle goes away from workpiece.
- Various tip assemblies in standard kit to fulfill cutting, welding and weldseam cleaning. Assembly of remote cleaning is optional.
- Wide welding seam, low porosity and excellent melting pool protection.
- Wire feeder as optional to expand application range.
Technical Data
| Fiber Interface |
QBH |
| Clear Aperture |
10 mm |
| Collimation Focal Length |
60 mm |
| Focusing Focal Length |
150/200 mm |
| Wobble Width |
0-5mm (Weld)
0-10mm (Weld Seam Clean)
0-80mm (Remote Clean) |
| Cover Glasses
– Focusing Side (Top/Bottom) |
18 * 2 mm |
| Assist Gas Flow |
15-25L/min |
| Weight |
~ 0.9 kg |
| Optional Tip Components |
Cutting Assembly/ Welding Assembly/ Cleaning Assembly |
